What is the Usage and Maintenance Guide for Drill String Strong Magnetic Tools ?

I. Usage Instructions

1. Pre-Operation Inspection

- Ensure the magnet surface is free of cracks, rust, or oil contamination.

- Check threaded connections for integrity to prevent downhole detachment.

- Verify magnetic strength (e.g., using a Gauss meter) to confirm it meets operational requirements.

2. Downhole Operation

- Lower the drill string slowly to the target depth, avoiding sudden impacts against the wellbore or fish.

- When approaching metal debris, rotate the drill string at low RPM (≤30) to enhance magnetic attraction.

- Retrieve the string smoothly after adsorption to prevent losing captured debris.

3. Applicable Scenarios

- Primarily used for retrieving ferromagnetic materials (e.g., bit fragments, casing chips). Not suitable for non-magnetic metals (e.g., copper, aluminum).

- Recommended for vertical or low-angle wells; in high-angle wells, use with a centralizer.

II. Maintenance & Care Guidelines

1. Cleaning

- Clean the magnet surface immediately after use with diesel or a specialized solvent to remove metal shavings and drilling mud.

- Avoid scraping the magnet with sharp tools to prevent magnetic degradation.

2. Demagnetization Prevention

- Store away from strong magnetic fields (e.g., motors, welding machines).

- Separate multiple magnets with non-magnetic spacers (e.g., wooden blocks) to avoid collisions.

3. Regular Inspection

- Measure magnetic flux every 3 months; return for recharging if strength drops by >15%.

- Check sealing rings for wear (prevents fluid ingress and corrosion).

4. Storage Requirements

- Store in a dry environment (humidity ≤60%, temperature -20°C to 50°C).

- Apply anti-rust grease and wrap in moisture-proof paper for long-term storage.

III. Troubleshooting

- Weak Adsorption: Clean the magnet or recharge if demagnetized.

- Thread Damage: Do not force connections; repair or replace damaged parts.

- Fishing Failure: Confirm if the fish is ferromagnetic; switch to alternative tools (e.g., junk baskets) if needed.

For specific operational parameters (e.g., load capacity, temperature limits by model), provide the tool model or well conditions for further guidance.
